IDEC CORPORATION
IDEC株式会社从1945年11月创业以来，为了“创造理想的人机环境”，以追求安全性及信赖性为主题，开发出了性能卓越的产品，事业得到了长足发展。 我们将继续面向工业自动化的未来，凭借半个多世纪积累的技术、经验以及智慧，在不断地发展现有事业的前提下，积极地挑战、开拓新的事业领域，成为您真正的全球性伙伴。 目前，IDEC集团有21个子公司，其中日本国内8个公司、海外13个公司。我们将更加齐心合力，努力为各位客户提供尽善尽美的服务。
商品列表
AL6M-M13-A
供应商: Verical
分类: Pushbutton
描述: Switch Push Button N.O./N.C. SPDT Round Button 1A 250VAC 250VDC Momentary Contact Quick Connect/Solder Panel Mount
Mounting Style: Panel Operating Temp Range: -25C to 55C Mechanical Life: 1000000 Operating Temperature Min Deg. C: -25C Operating Temperature Max Deg. C: 55C Type: Momentary Contact Terminal Type: Quick Connect/Solder AC Voltage Rating (Max): 250 Current Rating (Max): 1@120VAC 24VDC(A) Illumination Type: LED/LENS Pole Throw Configuration: SPDT Product Length (mm): 23.5(mm) Product Depth (mm): 23.5(mm) Actuator Style: Round Button Product Height (mm): 45.5(mm) Switch Configuration: N.O./N.C. DC Voltage Rating (Max): 250 Contact Material: GOLD CLAD SILVER
供应商: Verical
分类: Pushbutton
描述: Switch Push Button N.O./N.C. SPDT Round Button 1A 250VAC 250VDC Momentary Contact Quick Connect/Solder Panel Mount
Mounting Style: Panel Operating Temp Range: -25C to 55C Mechanical Life: 1000000 Operating Temperature Min Deg. C: -25C Operating Temperature Max Deg. C: 55C Type: Momentary Contact Terminal Type: Quick Connect/Solder AC Voltage Rating (Max): 250 Current Rating (Max): 1@120VAC 24VDC(A) Illumination Type: LED/LENS Pole Throw Configuration: SPDT Product Length (mm): 23.5(mm) Product Depth (mm): 23.5(mm) Actuator Style: Round Button Product Height (mm): 45.5(mm) Switch Configuration: N.O./N.C. DC Voltage Rating (Max): 250 Contact Material: GOLD CLAD SILVER
AB6Q-M1-B
供应商: Verical
分类: Pushbutton
描述: Switch Push Button N.O./N.C. SPDT Square Button 1A 250VAC 250VDC Momentary Contact Quick Connect/Solder Panel Mount
Pole Throw Configuration: SPDT Mounting Style: Panel Operating Temp Range: -25C to 55C Actuator Style: Square Button Mechanical Life: 1000000 Operating Temperature Min Deg. C: -25C Operating Temperature Max Deg. C: 55C Illumination Type: Not Required Type: Momentary Contact Switch Configuration: N.O./N.C. Terminal Type: Quick Connect/Solder AC Voltage Rating (Max): 250 DC Voltage Rating (Max): 250 Contact Material: GOLD CLAD SILVER Current Rating (Max): 1@120VAC 24VDC(A)
供应商: Verical
分类: Pushbutton
描述: Switch Push Button N.O./N.C. SPDT Square Button 1A 250VAC 250VDC Momentary Contact Quick Connect/Solder Panel Mount
Pole Throw Configuration: SPDT Mounting Style: Panel Operating Temp Range: -25C to 55C Actuator Style: Square Button Mechanical Life: 1000000 Operating Temperature Min Deg. C: -25C Operating Temperature Max Deg. C: 55C Illumination Type: Not Required Type: Momentary Contact Switch Configuration: N.O./N.C. Terminal Type: Quick Connect/Solder AC Voltage Rating (Max): 250 DC Voltage Rating (Max): 250 Contact Material: GOLD CLAD SILVER Current Rating (Max): 1@120VAC 24VDC(A)
LB7L-A1T54PW
供应商: Verical
分类: Pushbutton
描述: Switch Push Button N.O./N.C. SPDT Flush Square Button 0.1A 125VAC 30VDC Maintained Contact Panel Mount Quick Connect/Solder
Mounting Style: Panel Product Depth (mm): 22(mm) Product Length (mm): 22(mm) Operating Temperature Min Deg. C: -25C Operating Temperature Max Deg. C: 60C Terminal Type: Quick Connect/Solder Operating Temp Range: -25C to 60C DC Voltage Rating (Max): 30 Product Height (mm): 36.9(mm) AC Voltage Rating (Max): 125 Actuator Style: Flush Square Button Pole Throw Configuration: SPDT Current Rating (Max): 0.1(A) Type: Maintained Contact Mechanical Life: 2000000 Contact Material: Silver Switch Configuration: N.O./N.C. Illumination Type: Led
供应商: Verical
分类: Pushbutton
描述: Switch Push Button N.O./N.C. SPDT Flush Square Button 0.1A 125VAC 30VDC Maintained Contact Panel Mount Quick Connect/Solder
Mounting Style: Panel Product Depth (mm): 22(mm) Product Length (mm): 22(mm) Operating Temperature Min Deg. C: -25C Operating Temperature Max Deg. C: 60C Terminal Type: Quick Connect/Solder Operating Temp Range: -25C to 60C DC Voltage Rating (Max): 30 Product Height (mm): 36.9(mm) AC Voltage Rating (Max): 125 Actuator Style: Flush Square Button Pole Throw Configuration: SPDT Current Rating (Max): 0.1(A) Type: Maintained Contact Mechanical Life: 2000000 Contact Material: Silver Switch Configuration: N.O./N.C. Illumination Type: Led
AS6M-32Y2P
供应商: Verical
分类: Switch Selector
描述: Switch Selector N.O./N.C. DPDT 45° Knob 1A 250VAC 250VDC Quick Connect/Solder 250000Cycles Panel Mount
供应商: Verical
分类: Switch Selector
描述: Switch Selector N.O./N.C. DPDT 45° Knob 1A 250VAC 250VDC Quick Connect/Solder 250000Cycles Panel Mount
HW4L-A1F20QD-W-240V
供应商: Verical
分类: Pushbutton
描述: Switch Push Button N.O. DPST Flush Round Button 10A 440VAC 220VDC 745.7VA Maintained Contact Screw Panel Mount
Pole Throw Configuration: DPST Mounting Style: Panel Contact Material: Silver Mechanical Life: 500000 Operating Temp Range: -25C to 50C Operating Temperature Max Deg. C: 50C Operating Temperature Min Deg. C: -25C Actuator Style: Flush Round Button Switch Configuration: N.O. Terminal Type: Screw Type: Maintained Contact Illumination Type: LED/LENS AC Voltage Rating (Max): 440 DC Voltage Rating (Max): 220 Current Rating (Max): 10@110VAC(A)
供应商: Verical
分类: Pushbutton
描述: Switch Push Button N.O. DPST Flush Round Button 10A 440VAC 220VDC 745.7VA Maintained Contact Screw Panel Mount
Pole Throw Configuration: DPST Mounting Style: Panel Contact Material: Silver Mechanical Life: 500000 Operating Temp Range: -25C to 50C Operating Temperature Max Deg. C: 50C Operating Temperature Min Deg. C: -25C Actuator Style: Flush Round Button Switch Configuration: N.O. Terminal Type: Screw Type: Maintained Contact Illumination Type: LED/LENS AC Voltage Rating (Max): 440 DC Voltage Rating (Max): 220 Current Rating (Max): 10@110VAC(A)
