MICRO COMMERCIAL COMPONENTS
商品列表
GBJ3502BP
供应商: Verical
分类: Bridge Rectifier
描述: Diode Rectifier Bridge Single 200V 35A 4-Pin(4+Tab) Case GBJ Bulk/Tube
Mounting: Through Hole Peak Non-Repetitive Surge Current (Max): 350(A) Phase Type: Single Phase Operating Temp Range: -55C to 150C Package Type: CASE GBJ Packaging: BULK/TUBE Peak Rep Rev Volt: 200(V) Pin Count: 4 +Tab Rev Curr: 10(mA) Number of Elements: 1 Operating Temperature Classification: Military Forward Voltage: 1.05(V) RMS Voltage (Max): 140(V) Avg. Forward Curr (Max): 35(A) Rad Hardened: No
供应商: Verical
分类: Bridge Rectifier
描述: Diode Rectifier Bridge Single 200V 35A 4-Pin(4+Tab) Case GBJ Bulk/Tube
Mounting: Through Hole Peak Non-Repetitive Surge Current (Max): 350(A) Phase Type: Single Phase Operating Temp Range: -55C to 150C Package Type: CASE GBJ Packaging: BULK/TUBE Peak Rep Rev Volt: 200(V) Pin Count: 4 +Tab Rev Curr: 10(mA) Number of Elements: 1 Operating Temperature Classification: Military Forward Voltage: 1.05(V) RMS Voltage (Max): 140(V) Avg. Forward Curr (Max): 35(A) Rad Hardened: No
MMBZ5232B-TP
供应商: Verical
分类: Zener
描述: Diode Zener Single 5.6V 5% 350mW 3-Pin SOT-23 T/R
Pin Count: 3 Mounting: Surface Mount Rev Curr: 0.005(mA) Zener Voltage: 5.6 Operating Temp Range: -55C to 150C Operating Temperature Classification: Military Knee Impedance: 11 Voltage Tolerance: 5% Packaging: Tape and Reel Rad Hardened: No Power Dissipation: 500mW Package Type: SOT-23 Configuration: Single Zener Test Current: 20mA Test Current (It): 20(mA)
供应商: Verical
分类: Zener
描述: Diode Zener Single 5.6V 5% 350mW 3-Pin SOT-23 T/R
Pin Count: 3 Mounting: Surface Mount Rev Curr: 0.005(mA) Zener Voltage: 5.6 Operating Temp Range: -55C to 150C Operating Temperature Classification: Military Knee Impedance: 11 Voltage Tolerance: 5% Packaging: Tape and Reel Rad Hardened: No Power Dissipation: 500mW Package Type: SOT-23 Configuration: Single Zener Test Current: 20mA Test Current (It): 20(mA)
US1KE-TP
供应商: Verical
分类: Rectifier
描述: Diode Switching 800V 1A 2-Pin SMAE T/R
Forward Voltage: 1.7(V) Mounting: Surface Mount Package Type: SMAE Peak Rep Rev Volt: 800(V) Rev Curr: 10(uA) Operating Temperature Classification: Automotive Packaging: Tape and Reel Rad Hardened: No Pin Count: 2 Peak Non-Repetitive Surge Current: 30(A) Rev Recov Time: 75(ns) Operating Temp Range: -50C to 150C Configuration: Single Rectifier Type: Switching Diode
供应商: Verical
分类: Rectifier
描述: Diode Switching 800V 1A 2-Pin SMAE T/R
Forward Voltage: 1.7(V) Mounting: Surface Mount Package Type: SMAE Peak Rep Rev Volt: 800(V) Rev Curr: 10(uA) Operating Temperature Classification: Automotive Packaging: Tape and Reel Rad Hardened: No Pin Count: 2 Peak Non-Repetitive Surge Current: 30(A) Rev Recov Time: 75(ns) Operating Temp Range: -50C to 150C Configuration: Single Rectifier Type: Switching Diode
BC557BAP
供应商: Verical
分类: BJT - General Purpose
描述: Trans GP BJT PNP 45V 0.1A 3-Pin TO-92 Ammo
Collector Current (DC) (Max): 0.1 A Collector-Base Voltage: 50(V) Collector-Emitter Voltage: 45(V) Emitter-Base Voltage: 5(V) Frequency: 150(MHz) Power Dissipation: 0.625(W) Mounting: Through Hole Operating Temp Range: -55C to 150C Package Type: TO-92 Packaging: Ammo Pack Pin Count: 3 Number of Elements: 1 Operating Temperature Classification: Military Category: Bipolar Small Signal Rad Hardened: No Transistor Polarity: PNP DC Current Gain: 180 Collector Current (DC): 0.1(A) Output Power: Not Required(W) Configuration: Single
供应商: Verical
分类: BJT - General Purpose
描述: Trans GP BJT PNP 45V 0.1A 3-Pin TO-92 Ammo
Collector Current (DC) (Max): 0.1 A Collector-Base Voltage: 50(V) Collector-Emitter Voltage: 45(V) Emitter-Base Voltage: 5(V) Frequency: 150(MHz) Power Dissipation: 0.625(W) Mounting: Through Hole Operating Temp Range: -55C to 150C Package Type: TO-92 Packaging: Ammo Pack Pin Count: 3 Number of Elements: 1 Operating Temperature Classification: Military Category: Bipolar Small Signal Rad Hardened: No Transistor Polarity: PNP DC Current Gain: 180 Collector Current (DC): 0.1(A) Output Power: Not Required(W) Configuration: Single
DB3TG-TP
供应商: Verical
分类: DIACs
描述: DIAC Diode 34V 0.015mA 2-Pin DO-35G T/R
Packaging: Tape and Reel
供应商: Verical
分类: DIACs
描述: DIAC Diode 34V 0.015mA 2-Pin DO-35G T/R
Packaging: Tape and Reel
1N6003B-TP
供应商: Verical
分类: Zener
描述: Diode Zener Single 13V 5% 500mW 2-Pin DO-35 T/R
Mounting: Through Hole Operating Temp Range: -65C to 200C Package Type: DO-35 Packaging: Tape and Reel Pin Count: 2 Rev Curr: 0.0001(mA) Operating Temperature Classification: Military Configuration: Single Rad Hardened: No Knee Impedance: 25Ohm Power Dissipation: 500mW Zener Voltage (Typ): 13V Voltage Tolerance: 5% Zener Test Current: 5mA Zener Voltage: 13V DELETED: Compliant
供应商: Verical
分类: Zener
描述: Diode Zener Single 13V 5% 500mW 2-Pin DO-35 T/R
Mounting: Through Hole Operating Temp Range: -65C to 200C Package Type: DO-35 Packaging: Tape and Reel Pin Count: 2 Rev Curr: 0.0001(mA) Operating Temperature Classification: Military Configuration: Single Rad Hardened: No Knee Impedance: 25Ohm Power Dissipation: 500mW Zener Voltage (Typ): 13V Voltage Tolerance: 5% Zener Test Current: 5mA Zener Voltage: 13V DELETED: Compliant
SK12-L-TP
供应商: Verical
分类: Rectifier
描述: Diode Schottky 20V 1A 2-Pin SMB T/R
Mounting: Surface Mount Operating Temp Range: -55C to 125C Operating Temperature Classification: Military Packaging: Tape and Reel Package Type: SMB Rad Hardened: No Rectifier Type: Schottky Diode Forward Voltage: 0.5(V) Peak Rep Rev Volt: 20(V) Rev Curr: 500(uA) Pin Count: 2 Peak Non-Repetitive Surge Current: 30(A) Configuration: Single Forward Current: 1000(mA)
供应商: Verical
分类: Rectifier
描述: Diode Schottky 20V 1A 2-Pin SMB T/R
Mounting: Surface Mount Operating Temp Range: -55C to 125C Operating Temperature Classification: Military Packaging: Tape and Reel Package Type: SMB Rad Hardened: No Rectifier Type: Schottky Diode Forward Voltage: 0.5(V) Peak Rep Rev Volt: 20(V) Rev Curr: 500(uA) Pin Count: 2 Peak Non-Repetitive Surge Current: 30(A) Configuration: Single Forward Current: 1000(mA)
