DIODES INC

Diodes Incorporated is a leading global manufacturer and supplier of high-quality application specific standard products within the broad discrete, logic, analog and mixed-signal semiconductor markets. Diodes serves the consumer electronics, computing, communications, industrial, and automotive markets.

商品列表
MMBZ5244B7F
供应商: Verical
分类: Zener
描述: Zener Diode Single 14V 5% 15Ohm 350mW 3-Pin SOT-23 T/R
Mounting: Surface Mount Operating Temp Range: -65C to 150C Package Type: SOT-23 Packaging: Tape and Reel Pin Count: 3 Rev Curr: 0.0001(mA) Operating Temperature Classification: Military Configuration: Single Rad Hardened: No Knee Impedance: 15 Power Dissipation: 0.35(W) Zener Voltage: 14 Voltage Tolerance: 5% Zener Test Current: 9mA Test Current (It): 9(mA) Type: Voltage Regulator
PI90LV047ALE
供应商: Verical
分类: Interface - LVDS
描述: LVDS Driver 500Mbps 0.45V 16-Pin TSSOP Tube
Package Type: TSSOP Propagation Delay Time: 1.7(ns) Pin Count: 16 Number of Drivers: 4 Mounting: Surface Mount Operating Temperature Classification: Industrial Operating Supply Voltage (Typ): 3.3(V) Operating Temp Range: -40C to 85C Differential Output Voltage: 0.45(mV) Rad Hardened: No Operating Temperature (Max): 85C Input Type: CMOS/TTL Operating Temperature (Min): -40C Number of Elements: 4 Transmission Data Rate: 62.5(MBps) Output Type: Driver Packaging: Rail/Tube Number of Receivers: 0
PI5L200WE
供应商: Verical
分类: Interface - Analog Switch Mux
描述: Analog Multiplexer Quad 2:1 16-Pin SOIC N Tube
Power Dissipation: 0.5(W) Package Type: SOIC N Pin Count: 16 Number of Inputs: 8 Number of Outputs: 4 Mounting: Surface Mount Operating Temperature Classification: Industrial Chip Enable Signals: Yes Power Supply Requirement: Single Operating Temp Range: -40C to 85C Single Supply Voltage (Max): 7(V) Single Supply Voltage (Typ): 3.3/5(V) Rad Hardened: No Multiplexer Configuration: Quad 2:1 Dual Supply Voltage (Typ): Not Required(V) Dual Supply Voltage (Min): Not Required(V) Dual Supply Voltage (Max): Not Required(V) Type: Analog Multiplexer Number of Channels: 4 Analog Switch ON Resistance: 22@3.3V(ohm) Analog Switch Turn On Time: 40@3.3V@-40C to 85C(ns) Analog Switch Turn Off Time: 20@3.3V@-40C to 85C(ns) Packaging: Rail/Tube Data Rate (Max): 135000(kbps) High Level Output Current: 120(mA) Input Signal Type: SINGLE Switch Control Logic: NOT REQUIRED Switch Normal Position: NOT REQUIRED Output Signal Type: SINGLE
BZT52C33Q-7-F
供应商: Verical
分类: Zener
描述: Zener Diode Single 33V 6.06% 80Ohm 500mW Automotive 2-Pin SOD-123 T/R
BAV23CQ-13-F
供应商: Verical
分类: Rectifier
描述: Rectifier Diode Small Signal Switching 250V 0.4A 50ns Automotive 3-Pin SOT-23 T/R
Mounting: Surface Mount Operating Temp Range: -65C to 150C Package Type: SOT-23 Packaging: Tape and Reel Pin Count: 3 Operating Temperature Classification: Military Configuration: Dual Common Cathode Rad Hardened: No Rectifier Type: Switching Diode Peak Non-Repetitive Surge Current: 9(A) Peak Rep Rev Volt: 250(V) Rev Curr: 0.1(uA) Rev Recov Time: 50(ns) Forward Voltage: 1.25(V) Forward Current: 400(mA) Product Height (mm): 0.98(mm) Peak Reverse Recovery Time: 50(ns) Maximum Forward Current: 400(mA) Peak Forward Voltage: 1.25(V) Power Dissipation (Max): 350(mW) Product Depth (mm): 1.3(mm) Peak Reverse Current: 0.1(uA)
MSB25MH
供应商: Verical
分类: Unsorted
描述: MSB25MH
AP7343D-29FS4-7B
供应商: Verical
分类: Linear Regulator
描述: LDO Regulator Pos 2.9V 0.3A 4-Pin X2-DFN EP T/R
Packaging: Tape and Reel Operating Temp Range: -40C to 85C Dropout Voltage@Current (Max): 0.3@300mA Dropout Voltage@Current (Typ): 0.25@300mA Polarity: Positive Input Voltage (Min): 1.7(V) Quiescent Current: 60(uA) Load Regulation: 30mV Type: LDO Package Type: X2-DFN EP Number of Outputs: 1 Output Voltage: 2.9(V) Output Current: 300(mA) Input Voltage: 5.25(V) Output Type: Fixed Line Regulation: 0.1%/V Power Dissipation: 0.4(W)
DDZ9703T7
供应商: Verical
分类: Zener
描述: Zener Diode Single 16V 5% 150mW 2-Pin SOD-523 T/R
Mounting: Surface Mount Operating Temp Range: -65C to 150C Package Type: SOD-523 Packaging: Tape and Reel Pin Count: 2 Rev Curr: 0.00005(mA) Operating Temperature Classification: Military Configuration: Single Rad Hardened: No Power Dissipation: 0.15(W) Zener Voltage: 16 Voltage Tolerance: 5% Zener Test Current: 0.05mA Test Current (It): 0.05(mA) Type: Voltage Regulator
LTTH806SDFW
供应商: Verical
分类: Rectifier
描述: Diode Switching 600V 8A
GBJ1508_HF
供应商: Verical
分类: Bridge Rectifier
描述: GBJ1508_HF
