店铺热销
产品参数
| 参数名称 | 参数值 |
|---|---|
| Product Lifecycle | 量产 |
| Package | 8-Lead MSOP |
| # of Amps | 1 |
| Vos (max) | 125µV |
| Vos TC (max) | 5µV/°C |
| Gain Set | Resistor |
| Gain (min) | 1V/V |
| Gain (max) | 1000V/V |
| BW - low gain (typ) | 1.5MHz |
| Ibias (max) | 10pA |
| Input Voltage Noise (typ) | 14nV/rtHz |
| Iq/Amp (max) | 750µA |
| Vs span (min) | 4.5V |
| Vs span (max) | 36V |
| Short Circuit Current | 15mA |
| 0.1 to 10 Hz VNoise (typ) | 800nV p-p |
| Ibias TC (typ) | 100nA/°C |
| CMRR - Low Gain (min) | 86dB |
| CMRR - High Gain (min) | 100dB |
| Current Noise Density (typ) | 1fA/rtHz |
| In V+ Headroom (max) | 2V |
| In V- Headroom (max) | -100mV |
| Out V+ Headroom (max) | 300mV |
| Out V- Headroom (max) | 300mV |
| Output Voltage Noise (typ) | 90nV/rtHz |
| Gain TC - Low Gain (max) | 5ppm/°C |
| Gain TC - High Gain (max) | 50ppm/°C |
| Gain Error - High Gain (max) | 0.2% |
| Gain Error - Low Gain (max) | 0.04% |
| Ios (max) | 600fA |
| Ios drift (typ) | 10nA/°C |
| Rail to Rail | Output |
| Eval / Ref Circuit | Evaluation board, Reference circuit |
| Export Classification | EAR99 |
| Automotive | Yes |
| Reliability Level | Automotive,EP |
| Temp Range | -55 to 125°C |
| Package Area | 16.48mm² (8-Lead MSOP) (AD8220ARMZ)mm² |
| Package Height | 1.1mm (8-Lead MSOP) (AD8220ARMZ)mm |
| Launch Date | 2008-02-25 |
| EP | Yes |
| Design Tools | In-Amp Diamond Plot Tool, LTspice |
| Amp Features | JFET Input |
| Cdiff (typ) | 2.5pF |
| Ccm (typ) | 10pF |
| Rdiff (typ) | 20TOhms |
| Rcm (typ) | 5TOhms |
| Output Type | Single Ended |
| Iq/Amp (typ) | 750µA |
